Trailer Hub and Drum Assembly 5 on 4-1/2" Bolt Circle, 1,750lb Capacity for Tapered Spindle
10" Hub has 5 on 4-1/2" circle for a 1-3/8" To 1-1/16" tapered spindles for a 3,500lb axle with a hub capacity of 1,750lbs. Includes pressed in bearing races with a pilot diameter 2.59", flange diameter 6.5". 1/2"-20 lugs.
2½" deep inside for use with 10" x 2¼" electric or hydraulic brakes.
Hub assembly includes:
- L-68149 Inner Bearing,
- L-44649 Outer Bearing,
- SL-172 Grease Seal,
- SCP-100 Cotter Pin,
- DC-1505 Dust Cap,
- (5) STN-506 Lug Nuts
10" Hub has 5 on 4-1/2" circle for a 1-3/8" To 1-1/16" tapered spindles for a 3,500lb axle with a hub capacity of 1,750lbs. Includes pressed in bearing races with a pilot diameter 2.59", flange diameter 6.5". 1/2"-20 lugs.
2½" deep inside for use with 10" x 2¼" electric or hydraulic brakes.
Hub assembly includes:
- L-68149 Inner Bearing,
- L-44649 Outer Bearing,
- SL-172 Grease Seal,
- SCP-100 Cotter Pin,
- DC-1505 Dust Cap,
- (5) STN-506 Lug Nuts
Description
10" Hub has 5 on 4-1/2" circle for a 1-3/8" To 1-1/16" tapered spindles for a 3,500lb axle with a hub capacity of 1,750lbs. Includes pressed in bearing races with a pilot diameter 2.59", flange diameter 6.5". 1/2"-20 lugs.
2½" deep inside for use with 10" x 2¼" electric or hydraulic brakes.
Hub assembly includes:
- L-68149 Inner Bearing,
- L-44649 Outer Bearing,
- SL-172 Grease Seal,
- SCP-100 Cotter Pin,
- DC-1505 Dust Cap,
- (5) STN-506 Lug Nuts
