Trailer Hub and Drum Assembly - 4 on 4" Bolt Circle, 1,250lb Capacity for 1-1/16" ID Straight Spindles
7" Hub and DrumĀ has 4 on 4" bolt circle for a 2,000lb axle with hub capacity of 1,250lbs. Includes pressed in bearing races with a pilot diameter 2.5", flange diameter 5.56" and measures 4-1/4" tall.
2" deep inside for use with 7" electric or hydraulic brakes.
This kit provides grease seals to work with axles that have 1.25" OR 1.50" seal surfaces.
Ā
* Grease seal may vary in construction (metal ring or rubber ring) - dimensions are the same and either version will work very well.
Hub assembly includes:
- (2) L-44649 Inner and Outer Bearings,
- (1) SL-150-1 (1.50" I.D.) and Ā (1) SL-122 (1.249" ID) Grease Seals,
- SCP-100 Cotter Pin,
- DC-1505 Dust Cap,
- (4) STN-506 Lug Nuts
7" Hub and DrumĀ has 4 on 4" bolt circle for a 2,000lb axle with hub capacity of 1,250lbs. Includes pressed in bearing races with a pilot diameter 2.5", flange diameter 5.56" and measures 4-1/4" tall.
2" deep inside for use with 7" electric or hydraulic brakes.
This kit provides grease seals to work with axles that have 1.25" OR 1.50" seal surfaces.
Ā
* Grease seal may vary in construction (metal ring or rubber ring) - dimensions are the same and either version will work very well.
Hub assembly includes:
- (2) L-44649 Inner and Outer Bearings,
- (1) SL-150-1 (1.50" I.D.) and Ā (1) SL-122 (1.249" ID) Grease Seals,
- SCP-100 Cotter Pin,
- DC-1505 Dust Cap,
- (4) STN-506 Lug Nuts
Description
7" Hub and DrumĀ has 4 on 4" bolt circle for a 2,000lb axle with hub capacity of 1,250lbs. Includes pressed in bearing races with a pilot diameter 2.5", flange diameter 5.56" and measures 4-1/4" tall.
2" deep inside for use with 7" electric or hydraulic brakes.
This kit provides grease seals to work with axles that have 1.25" OR 1.50" seal surfaces.
Ā
* Grease seal may vary in construction (metal ring or rubber ring) - dimensions are the same and either version will work very well.
Hub assembly includes:
- (2) L-44649 Inner and Outer Bearings,
- (1) SL-150-1 (1.50" I.D.) and Ā (1) SL-122 (1.249" ID) Grease Seals,
- SCP-100 Cotter Pin,
- DC-1505 Dust Cap,
- (4) STN-506 Lug Nuts
